Transmission & driveline » Transaxle & transmission (TM) » P2765 Clutch B speed sensor
DTC Logic

DTC DETECTION LOGIC

DTC

Trouble diagnosis name

DTC detection condition

Possible causes

P2765

Input/Turbine Speed Sensor B Circuit

The secondary speed sensor value is less than 150 rpm continuously for 5 seconds or more under the following diagnosis conditions:

- Diagnosis conditions

- Primary pulley speed: 1,000 rpm or more

- TCM power supply voltage: More than 11 V

- Harness or connector (Secondary speed sensor circuit is open or shorted)

- Secondary speed sensor

The secondary pulley speed sensor value is 240 rpm or less continuously for 500 msec or more under the following diagnosis conditions:

- Diagnosis condition

- 10-msec-ago secondary pulley speed: 1,000 rpm or more

- TCM power supply voltage: More than 11 V

DTC CONFIRMATION PROCEDURE

CAUTION: Be careful of the driving speed.

1.PREPARATION BEFORE WORK

If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at least 10 seconds, then perform the next test.

>> GO TO 2.

2.CHECK DTC DETECTION

Selector lever : "D" position

Vehicle speed : 55 km/h (34 MPH) or more

Is "P2765" detected?

YES >> Go to TM "Diagnosis Procedure".

NO >> INSPECTION END
